ATX 12 V Fixed cables 80...
10800
Nuevo
5 artículos
The 80 PLUS® 230V EU certification indicates that a high percentage of the electricity is converted into useful power, therefore there is less heat lost and more money saved on the electricity bill.
The 80 PLUS® 230V EU certification guarantees greater than 82 %, 85 % and 82 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. Sea Sonic’s A12 Series is an economical choice with great performance and high built-in value.
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible.
| Technical Specifications | ||
|---|---|---|
| 80PLUS® | 230V EU | |
| Form Factor | Intel ATX 12 V | |
| Dimensions | 140 mm (L) x 150 mm (W) x 86 mm (H) | |
| Fan Information | Fan Size | 120 mm |
| Fan Control | Seasonic S2FC | |
| Fan Bearing | Sleeve bearing | |
| Life Expectancy | 30,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Fixed cable |
| Cable type | Flat black cables | |
| Electrical Features | Operating Temperature | 40 °C |
| MTBF @ 25 °C, excl. fan | 100,000 hours | |
| AC Input | Fixed 230 V | |
| Protection | OPP, OVP, UVP, SCP | |
| Safety and Environmental | Safety and EMC | TUV, CB , CCC, CE, EAC |
| Environmental Compliance | Energy Star, RoHS, WEEE, REACH | |
| Warranty | 3 Years | |
| Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 200 V - 240 V | |||||
| Current: 4 A | ||||||
| Frequency: 50 Hz - 60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 18 A | 18 A | 48 A | 0.3 A | 2.5 A | |
| 90 W | 576 W | 3.6 W | 12.5 W | |||
| Total continuous power | 600 W | |||||
| Connector | Connector Count |
|---|---|
| Main Power (24/20 pins) | 1 |
| CPU (8/4 pins) | 1 |
| PCIe (8/6 pins) | 4 |
| SATA | 4 |
| Peripheral | 2 |
